Studio Due City Color 400

Podrobný popis

architektonické svítidlo, colorchanger CYM mix, lampa 2X CDM-T 150W, shutter, control panel, funkce master-slave, hmotnost 31kg, IP 66 OUTDOOR

LAMP:
-2 x CDM-T 150W/942 (PHILIPS)
-Discharge MasterColour
-Color temperature: 4.200°K
-Average lamp life: 6.000 hours
-Luminous flux: 2 x 14.000 lm
-Burning position: Universal

OPTIC COLOUR SYSTEM:
-Full CYM color mixing, unlimited variety of colours and shades
-High resolution stepper motors
-With shutter

BEAM ANGLE: (50%): 45°

IP RATE = IP 66

CONTROL INPUT:
-Standard interface: RS-485; opto-couplet input
-Protocol: USITT DMX 512

SETUP and CONFIGURATION:
-On the control panel with menu and buttons

AUTOMODE:
-Stand-alone control: auto mode function master/slave (synchro mode) with 27 programs

DMX CHANNELS:
-ch 1 = motor speed
-ch 2 = cyan
-ch 3 = yellow
-ch 4 = magenta
-ch 5 = dimmer
-ch 6 = basic colours/rainbow
-ch 7 = remote reset

POWER SUPPLY:
-Rated voltage: 230V/50Hz-230V/60Hz
-Rated power: 500Va
-Rated current: 2,2A (230V)

POWER FACTOR CORRECTOR: built-in cos O 0.9

FUSES:
-Lamp fuse: 5.0A/250V (delay time)
-Electronic fuse: 2.0A/250V (delay time)
