Studio Due Mini City 150W

Podrobný popis

architektonické svítidlo, colorchanger CYM mix, lampa CDM-T 150W, funkce master-slave, váha 15kg, IP 66 OUTDOOR

LAMP:
-Mastercolour CDM-T 150W/942
-Lamp life: 6000 hours
-Color temperature: 4200 K
-Luminous flux: 14000 lumen
-Burning position: Universal

BEAM ANGLE:
-(50% intensity): 15° (on request parabole for 28° wide beam)

OPTIC COLOUR SYSTEM:
-Full CYM color mixing unlimited variety of colors and shades
-High resolution stepper motor
-Color crossfades can be programmed at four different speeds or in real time

SHUTTER + DIMMER (art. 0102 only)

IP RATE = IP 66

CONTROL INPUT:
-Standard interface: RS-485; opto-couplet
-Input Protocol: USITT DMX 512

AUTOMODE:
-Stand-alone control: auto mode function master/slave (synchro mode) with 27 programs

DMX CHANNELS:
-ch1 = motor speed
-ch2 = cyan (continuosly variable)
-ch3 = yellow (continuosly variable)
-ch4 = magenta (continuosly variable)
-ch5 = dimmer (art. 0102 only)
-ch6 = basic color

POWER SUPPLY (magnetic ballast):
-Rated voltage: 230V/50Hz
-On request: 200V/50Hz; 208V/60Hz; 230V/60Hz; 240V/50Hz
-Rated current: 1,1A
-Rated power: 250VA

POWER FACTOR CORRECTOR: built-in cos O 0.9
