Studio Due Mini City 250W

Podrobný popis

architektonické svítidlo, colorchanger CYM mix, lampa MSD 250W, proměnný úhel, shutter, control panel, funkce master-slave, IP 66 OUTDOOR

LAMP:
-MSD 250/2 (discharge)
-Lamp life: 2000 hours
-Color temperature: 8500 K
-Luminous flux: 18000 lumen
-Beam angle: (controlled by stepper motors)
-varying from 11° to 15° with standard parabole
-varying from 20° to 28° with wide parabole

COLOR SYSTEM :
-Full CYM color mixing unlimited variety of colors and shades
-High resolution stepper motor

OPTIC :
-New concept optical system (patent pending)

DIMMER + SHUTTER
-0-100% mechanical

IP RATE :
-IP 66

SETTING :
-Buil-in microprocessor with display

INPUT SIGNAL :
-With DMX 512-RS485 optoisolated

POWER SUPPLY :
-rated voltage 200/208/230/240Vac
-rated frequency 50 or 60Hz
-rated power 350VA
-(optional 100/120Vac)
-Power factor corrector: built-in cos O0.9

DMX CHANNELS :
-ch1 = motor speed
-ch2 = cyan (continuosly variable)
-ch3 = yellow (continuosly variable)
-ch4 = magenta (continuosly variable)
-ch5 = dimmer
-ch6 = beam angle
-ch7 = local reset/lamp off
